Jeti Tauro H3300
Extremely productive hybrid wide-format UV LED inkjet printer range.
Download brochure Apply consultation
- Hybrid
- Up to 1,280 m²/h – 13,778 ft²/h
- Up to 330 cm – 130 in
- Automatable
- Speed & colors upgradable
Driven by relentless determination, the rugged Tauro is ready to take on any print job, ensuring you hit the bull’s eye 24/7.
With its versatile configurations, this sturdy beast unleashes fierce performance, allowing you to experience rugged reliability and charge ahead with primal force.Our fastest hybrid press offers 24/7 productivity and award-winning quality on a wide range of rigid and flexible materials with the lowest ink consumption. With its many automation options, it’s the perfect solution for larger print service providers.
Application:
drag
Benefits
- Versatile printer: tackles nearly all sign & display jobs, as well as packaging;
- Heavy-duty build for 24/7 printing with impressive productivity;
- Award-winning quality with excellent solid colors and a neutral gray balance;
- Varnish for extra brilliance and impact;
- Several automation options to up your production efficiency when printing long runs or multiple boards;
- Great autonomy gives you peace of mind;
- UV LED technology brings economic and ecological benefits;
- Thin Ink Layer technology for lowest ink consumption;
- Powered by smart Asanti workflow software.
Printer models
Tauro H3300 S
Tauro H3300 HS
Tauro H3300 UHS
Tauro H3300 XUHS
- Up to 450 m²/h
- 4 rows of print heads
- Field upgradable to a 6-row CMYKck
- Available options: white, primer
- Up to 680 m²
- 6 rows up print heads
- 4 or 6 colors
- 2x CMYK: focus on productivity
- CMYKck: enhanced image quality
- CCMYKKck: superior image quality thanks to extra redundancy in dark colors
- Available options: white, primer, varnish
- Up to 905 m²
- 8 rows of print heads
- 4, 6 or 7 colors
- 2 x CMYK: focus on productivity
- CCMYKKck: superior image quality thanks to extra redundancy in dark colors
- CMYKKcmk: enhanced image quality with optimal light & mid-tone colors
- Advanced automation to keep up with fast printing modes
- Extended vacuum for cardboard printing
- Available options: white, primer, varnish
- Up to 1280 m²/h
- 12 rows of print heads
- 4 or 7 color
- CCMMYYKK: focus on productivity
- CMYKKcmk: enhanced image quality with optimal light & mid-tone colors
- Extended vacuum for cardboard printing
- Available options: white, primer, varnish
Loading/unloading configurations
Manual loading and unloading
- Input and output tables for single or multiple board printing
- Perfect for short runs or handling different types of media
- Optional 3-point alignment bar on the input tables allows for easy and accurate media alignment. This supports more precise double-sided printing of thin media or skewed media, as well as correct cutting, e.g. of cardboard for packaging.
- Embedded continuous print solution enhances productivity in rigid mode as it narrows down the gap between two consecutive boards
Semi-automation
- Manual loading table, automated unloader
- Optional 3-point alignment bar on the input tables allows for easy and accurate media alignment. This supports more precise double-sided printing of thin media or skewed media, as well as correct cutting.
¾ automation with automatic board feeder (ABF)
- Manual loading with automatic alignment and transport to the printer
- Ideal for shorter runs or fast and efficient changeover between different media sizes or types. The ABF takes over part of the operator’s tasks, including accurate alignment.
Full automation
- Automatic loading and unloading
- For larger runs or runs with multiple board stacks
- Multiple boards automatically, increasing your productivity
- While one board set is being printed, the next one is being prepared
- UHS models have an optional second gantry for the fastest printing modes
Light roll-to-roll
- For occasional, short single roll-to-roll or work
- Fast switchover between roll-to-roll and sheet mode
- Maximum weight of 200 kg per roll and a diameter of 250 mm
Flex roll-to-roll
- Remains docked, thus allowing swift switching between rigid and flexible media
- For roll-to-roll or roll-to-floor printing
- Single- or dual-roll printing
- Compact footprint; ergonomic & user-friendly
- Handling rolls up to 450 kg with a diameter of 400 mm
- All onboard concept: no roll switching needed between single- or dual-roll mode.
Flex roll-to-roll system: Maximize production efficiency
- Benefit from increased flexibility with the Flex RTR system. As it doesn’t need undocking when transitioning from rolls to boards or sheets – the input and output tables simply attach over the roll system – printer uptime is increased.
- The Flex RTR can handle both single- and dual-roll printing and features an integrated camera for accurate double-sided printing.
- The module has a compact footprint and is user-friendly: a single operator can effortlessly load media with the simple push of a button.
Master roll-to-roll
- Designed to handle very large and heavy rolls
- For roll-to-roll or roll-to-floor printing
- Single- or dual-roll printing
- Handling rolls up to 700 kg with a diameter of 600 mm
- Dockable rolls for easy switching between rolls and rigids.
Technical data
| Models | |||||
| Tauro H3300 S | Tauro H3300 HS | Tauro H3300 UHS | Tauro H3300 XUHS | ||
Tauro H3300 S – 6 colors (24 heads)
Options:
| Tauro H3300 HS – 6 colors (36 heads)
Tauro H3300 HS – 6 colors+ (48 heads) Tauro H3300 HS – 2 x 4 colors (48 heads)
Options:
| Tauro H3300 UHS – 6 colors+ (64 heads)
Tauro H3300 UHS – 7 colors (64 heads) Tauro H3300 UHS – 2 x 4 colors (64 heads)
Options:
| Tauro H3300 XUHS – 7 colors (96 heads)
Tauro H3300 XUHS – 2 x 4 colors (96 heads)
Options:
| ||
| Productivity | |||||
| Up to 450 m²/h (4,844 ft²/h) | Up to 680 m²/h (7,319 ft²/h) | Up to 905 m²/h (9,741 ft²/h) | Up to 1,280m²/h (13,778 ft²/h) | ||
| Media & printing specifications – Sheets & boards | |||||
| Maximum width | Base engine: 3.34 m (131.49” = 10.95 ft)
Feeder, stacker and ABF: 3.30 m (130” = 10.8 ft) | ||||
| Maximum length | Base engine: 4.0 m (157.48” = 13.12 ft)
Feeder: boards & flexible sheets: 2.65 m (104.33” = 8.69 ft) Stacker: boards & flexible sheets: 2.65 m (104.33” = 8.69 ft) ABF: combined with input & output tables: 4.0 m (157.48” = 13.12 ft) / / combined with stacker: 2.65m (104.33” = 8.69 ft) for boards and flexible sheets | ||||
| Minimum size | Base engine: A2: 42.0 cm x 59.4 cm (16.5” x 23.4 in)
Feeder, stacker and ABF: A1: 59.4 cm x 84.1 cm (23.4” x 33.1”) (in portrait) | ||||
| Thickness | Base engine: min. 0.2 mm (8 mil) – max. 5 cm (2”) media-dependent
Feeder, stacker and ABF: min. 0.2 mm (8 mil) – max. 2 cm (0.8”), media-dependent | ||||
| Weight | Base engine: 10 kg/m² (2 lb/ft2) evenly distributed – Sheets: from 200 g/m² (0.04 lb/ft2)
Feeder, stacker and ABF: 10 kg/m² (2 lb/ft2) with max. 25 kg (55.1 lb) per load cycle – Sheets: from 200 g/m² (0.04 lb/ft2) | ||||
| Borderless printing | Yes, with protection paper or tape on the belt | ||||
| Media & printing specifications – Roll-to-Roll | |||||
| Maximum width | Light roll-to-roll* Single roll: 3.2 m (126” = 10.5 ft)
Flex roll-to-roll Single roll: 3.3 m (130” = 10.83 ft) / Dual roll: 1.6 m (63” = 5.25 ft) Master roll-to-roll Single roll: 3.3 m (130” = 10.83 ft) / Dual roll: 1.6 m (63” = 5.25 ft) | ||||
| Minimum width | Light roll-to-roll* Single roll: 61 cm (24” = 2 ft)
Flex roll-to-roll Single & dual roll: 61 cm (24” = 2 ft) Master roll-to-roll Single & dual roll: 61 cm (24” = 2 ft) | ||||
| Maximum length | Full roll length (depends on total roll thickness, diameter and weight) | ||||
| Thickness | Light roll-to-roll* Single roll: max. 2 mm (0.08”) (80 mil) – min. 0.2 mm (0.008 in) (8 mil)
Flex roll-to-roll Single & dual roll: max: 2 mm (0.08”) (80 mil) – min: 0.2 mm (0.008 in) (8 mil) Master roll-to-roll Single & dual roll: max: 2 mm (0.08””) (80 mil) – min: 0.2 mm (0.008 in) (8 mil) | ||||
| Maximum weight | Light roll-to-roll* Single roll: up to 200 kg (440.92 lb) per roll in full width*, mounted at the center of the shaft
Flex roll-to-roll Single roll: up to 450 kg (992.08 lb) in full width*, mounted at the center of the shaft Dual roll: up to 450 kg (992.08 lb) per roll* (each roll centered on its shaft) Master roll-to-roll Single roll: up to 700 kg (1,543.24 lb) in full width*, mounted at the center of the shaft Dual roll: up to 700 kg (1,543.24 lb) per roll* (each roll centered on its shaft) * The maximum weight depends on the roll width. | ||||
| Maximum roll outside diameter | Light roll-to-roll* 250 mm (9.8”)
Flex roll-to-roll Single & dual roll: 400 mm (15.7”) Master roll-to-roll Single & dual roll: 600 mm (23.6”) | ||||
| Roll mounting | Pneumatic shafts for cores of 76.2 mm (3”) (standard), and 152.4 mm (6”) (optional) | ||||
| Borderless printing flexible media | Yes, with tape on the belt | ||||
| Media | |||||
| Media types | Rigid as well as flexible media. Check with your local Agfa representative for a detailed list. | ||||
| Print heads & inks | |||||
| Print heads | Piezoelectric Ricoh MH5420 | ||||
| Ink | Anuvia CMYKck + white and primer | Anuvia CMYKck + white, primer and varnish | Anuvia CMYKcmk + white, primer and varnish | Anuvia CMYKcmk + white, primer and varnish | |
| Image & text quality | |||||
| Image quality | Resolution up to 1200 dpi | ||||
| Text quality | 4 point | ||||
| Room conditions | |||||
| Temperature | 16-25°C (61-77°F) | ||||
| Relative humidity | 40-60% | ||||
| System integration RIP/workflow software | |||||
| Asanti, StoreFront, PrintSphere, third-party RIPs | |||||
